    Apollo2 SoC

    Always-On Power

    Apollo2 kv mobile 1

    Apollo2 is a highly integrated, ultra-low power SoC for battery-powered devices. Built on Ambiq’s patented SPOT® platform and powered by an Arm® Cortex®-M4 with FPU, it delivers exceptional energy efficiency and performance for always-on voice, advanced sensing, and intelligent edge applications — all within the smallest power budget. Available in a 4.5mm x 4.5mm, 64-pin BGA or a 2.5mm x 2.5mm, 49-pin WLCSP package, it’s built for headsets, hearing aids, smart cards, fingerprint readers, smartwatches, smart meters, and wireless sensor applications.

    Where to Buy
    Design Resources

    Take Charge of Your Life

    Apollo2 BGA AMAPH1KK-KBR
    Press Releases

    01

    Comprehensive Solution

    An ideal solution for battery-powered applications needing sensor measurement and data analysis, equipped with a comprehensive set of standard software development tools.

    02

    Multiple Serial Protocol Support

    A host processor can connect with the Apollo2 SoC over its serial slave port using I2C, SPI, or I2S protocols.

    03

    Extended Battery Life

    Enables months and years of battery life for products that currently only last days or months.

    04

    Greater Performance

    The Arm Cortex-M4 with FPU offers higher performance and significantly lower power consumption compared to 8-bit, 16-bit, and other similar 32-bit cores.

    Apollo2 in Action

    “Ambiq’s groundbreaking low-power technology is critical because consumers are demanding always-on, always-connected, always-aware devices with longer battery life and slimmer, more fashionable form factors.”

    Rico Zhang
    Smart Wearable Product Line President, Huawei

    See Apollo2 in Huawei Fitness Wearables
    New Year New You Work Wonders With Wearables 2048x1117 1

    Block Diagram Apollo2

    Block Diagram for Apollo2 MCU

    Specifications

    Ultra-Low Supply Current

    • < 10 μA/MHz executing from flash at 3.3 V
    • < 10 μA/MHz executing from RAM at 3.3 V
    • < 3 μA deep sleep mode with RTC at 3.3 V

    High-Performance Arm Cortex-M4 Processor

    • Up to 48 MHz clock frequency
    • Floating Point Unit (FPU)
    • Memory Protection Unit (MPU)
    • Wake-up interrupt controller with 32 interrupts

    Ultra-low Power Memory

    • Up to 1MB of flash memory for code/data
    • Up to 256KB of low power RAM for code/data
    • 16KB 2-way Associative Cache

    Ultra-Low Power Interface for On- and Off-Chip Sensors

    • 14-bit ADC,15 selectable input channels available
    • Up to 2.67 MS/s sampling rate
    • Voltage Comparator (VCOMP)
    • Temperature sensor with ±3°C accuracy after calibration

    Ultra-Low Power Flexible Serial Peripherals

    • 6x I2C/SPI masters with 128-byte bidirectional FIFO for communication with sensors, radios, and other peripherals
    • 1x I2C/SPI slave for host communications with 256-bytes LRAM area for FIFO/host support
    • 2x UART modules with 32-location Tx and Rx FIFOs
    • PDM for mono and stereo audio microphones
    • 1x 12S slave for PDM audio pass-through

    Rich Set of Clock Sources

    • 32.768 kHz crystal (XTAL) oscillator
    • Low Frequency RC (LFRC) oscillator (1.024 kHz)
    • High Frequency RC (HFRC) oscillator (48 MHz)
    • RTC based on Ambiq’s AM08X5/18X5 family

    Wide Operating Range

    • 1.755-3.63 V, -40°C to 85°C

    Applications

    • Headsets, earphones, wireless earbuds
    • Mobile accessories
    • Hearing aids
    • Always-listening, voice-activated appliances
    • Portable voice assistants
    • Remote controls
    • Smart cards
    • Fingerprint readers
    • Personal devices (smart watches, smart bands)
    • Smart meters
    • Wireless sensors
    • Activity and fitness monitors
    • Consumer electronics

    Package Options

    • 4.5 mm x 4.5 mm 64-pin BGA with 50 GPIO
    • 2.5 mm x 2.5 mm 49-pin WLCSP with 34 GPIO

    Ordering Information

    • AMAPH1KK-KBR (256KB RAM, 64-pin BGA)
    • AMAPH1KK-KCR (256KB RAM, 49-pin WLCSP)
    • AMAPHEVB (EVB)

    Apollo2 Evaluation Board

    Apollo2 SoC in the BGA package (AMAPH1KK-KBR)

    Low power reference design

    Multiple power/clock options

    Micro USB connector for power/download/debug

    Segger J-Link debugger

    Debugger-in / debugger-out ports

    Five user-controlled LEDs

    Three push buttons for application use, plus a reset push button

    Power slide switch with LED power indicator

    Five 8-12 pin Arduino-style headers for pin/power access to shield board(s)

    Multiple test points for power measurements

    CE Mark and RoHS compliant

    Apollo2 SoC EVB
    Apollo2 SoC EVB
    Apollo2 SoC EVB

    Where to Buy

    Apollo2 SoC 48 MHz 256KB BGA 2
    Apollo2 SoC 48 MHz 256KB BGA

    AMAPH1KK-KBR

    Apollo2 BGA
    Apollo2 SoC 48 MHz 256KB WLCSP 2
    Apollo2 SoC 48 MHz 256KB WLCSP

    AMAPH1KK-KCR

    Apollo2 WLCSP
    Apollo2 SoC EVB AMAPH1KK-KBR

    AMAPHEVB

    Apollo2 Evaluation Board

    Design Resources

    Additional Documentation

    • Set favorites
    • Get update notifications
    • Use search filters
    Visit Content Portal

    Video Library

    hqdefault
    hqdefault
    hqdefault

    Frequently Asked Questions (FAQ)

    • Apollo2 is Ambiq’s highly integrated, ultra-low power SoC for battery-powered devices, built on Ambiq’s patented SPOT® platform with an Arm® Cortex®-M4 processor.

    • Apollo2 is available in a 64-pin BGA or 49-pin WLCSP package, while Apollo2 Thin uses a single ultra-thin 300µm WLCSP package optimized for the most space-constrained designs, like smart cards.

    • An Arm® Cortex®-M4 processor with FPU (Floating Point Unit), combined with Ambiq’s SPOT® power-optimization technology.

    • Always-on voice, advanced sensing, and intelligent edge applications, including headsets, hearing aids, smart cards, fingerprint readers, smartwatches, smart meters, and wireless sensors.

    • A 4.5mm x 4.5mm, 64-pin BGA package with 50 GPIO, and a 2.5mm x 2.5mm, 49-pin WLCSP package with 34 GPIO.

    • Yes — the Apollo2 Evaluation Board (AMAPHEVB) is available for prototyping and development.
