    Apollo4 SoC

    Leading Edge AI

    The Apollo4 SoC is purpose-built for ultra-low power processing, secure development environments, and vibrant graphics for leading-edge AI applications.

    Design Resources
    Video Library

    Take Charge of Your Life

    01

    Ultra-efficient performance

    Up to 192 MHz processing with turboSPOT® efficiency as low as 5 µA/MHz, enabling powerful applications without sacrificing power consumption.

    02

    Built for complex workloads:

    Up to 2MB MRAM and 1.8MB SRAM to provide the headroom needed to execute complex algorithms, neural networks, and rich graphical interfaces directly on-device.

    03

    Expandable memory support

    Multi-bit SPI and eMMC interfaces make it easy to add external memory for larger datasets, models, or media.

    04

    Purpose-built for battery devices:

    Designed as an application processor or coprocessor for smartwatches, fitness bands, voice remotes, trackers, predictive health, and smart home devices.

    Block Diagram for the Ultra-Low Power Apollo4 SoC

    Specifications

    Ultra-Low Supply Current

    • 5 µA/MHz executing from MRAM (with cache)
    • Low-power sleep and deep sleep modes with selectable levels of RAM/cache retention

    High-Performance Arm Cortex-M4 Processor with FPU

    • Up to 192 MHz clock frequency
    • Floating Point Unit (FPU)
    • Memory Protection Unit (MPU)
    • Secure Boot

    Ultra-Low Power Memory

    • Up to 2MB of non-volatile MRAM for code/data
    • Up to 1.8MB of low-power RAM for code/data

    Ultra-Low Power Interface for On- and Off-Chip Sensors

    • 12-bit ADC, 11 selectable input channels
    • Up to 2.8 MS/s sampling rate
    • Temperature sensor with ±3°C accuracy

    Ultra-Low Power Flexible Serial Peripherals

    • 3x 2/4/8-bit SPI master interfaces
    • 8x I2C/SPI masters for peripheral communication
    • 1x SPI slave for host communications
    • 4x UART modules with flow control
    • 1x USB 2.0 HS/FS device controller
    • 1x SDIO (SD3.0)/1x eMMC (v4.51)

    Display

    • MIPI DSI 1.2 up to 500 Mbps
    • Up to 454 x 454 resolution
    • 4 layers with alpha blending
    • Frame Buffer Decompression

    Graphics

    • 2D/2.5D graphics accelerator
    • Full Alpha Blending
    • Texture and Frame Buffer Compression

    Audio Processing

    • 4x stereo Digital microphones
    • 2x full-duplex I2S ports with ASRC

    Rich Set of Clock Sources

    • 16-52 MHz and 32.768 kHz Crystal (XTAL) oscillators
    • 1 kHz Low Frequency RC (LFRC) oscillator
    • 2x High Frequency RC (HFRC) oscillator

    Power Management

    • Operating range: 1.71-2.2 V, -20°C to 60°C
    • SIMO buck
    • Multiple I/O voltages supported

    Applications

    • Smart watches/bands
    • Wireless sensors and IoT
    • Activity and fitness monitors
    • Children's watches
    • Animal trackers
    • Motion and tracking devices
    • Alarms and security system
    • Far-field voice remotes
    • Consumer medical devices
    • Predictive maintenance
    • Smart home

    Package Options

    • 5 mm x 5 mm, 146-pin BGA with 105 GPIO

    Ordering Information

    • MAP42KK-KBR-B2 (BGA)
