    Apollo4 Blue Lite

    Healthcare Reimagined

    apollo4blueLite front mobile

    The Apollo4 Blue Lite SoC is an ultra-low power solution for connected wearables and digital health devices. It combines an Arm® Cortex®-M4 processor with Bluetooth® Low Energy 5.4 connectivity, including AoA/AoD support, MRAM, SRAM, and Ambiq’s turboSPOT® dynamic performance scaling up to 192 MHz. Apollo4 Blue Lite can operate as an application processor or coprocessor for smartwatches, digital health devices, and other edge wearables.

    Where to Buy
    Design Resources

    Ultra-Low-Power Performance for Connected Edge Devices

    Apollo 4 blue lite
    Press Release

    01

    Ultra-Low-Power Performance

    Apollo4 Blue Lite combines MRAM, SRAM, and Ambiq’s turboSPOT® technology to dynamically scale processing performance up to 192 MHz while maintaining ultra-low-power operation.

    02

    Flexible Application or Coprocessor Design

    Apollo4 Blue Lite can serve as either an application processor or coprocessor, giving developers flexibility when designing connected edge and wearable devices.

    03

    Integrated Bluetooth Low Energy 5.4

    A 32-bit Arm® Cortex®-M4 processor with floating-point unit (FPU) and integrated Bluetooth® Low Energy 5.4 connectivity supports efficient processing and wireless connectivity in endpoint devices.

    04

    Designed for Digital Health and Wearables

    Apollo4 Blue Lite combines ultra-low-power operation, graphics acceleration, tracking capabilities, and Bluetooth connectivity for digital health devices, smartwatches, fitness monitors, and other connected wearables.

    Block Diagram Apollo4 Blue Lite

    Block Diagram for the Ultra Low Power Apollo4 Blue Lite

    Specifications

    Ultra-Low Supply Current

    • 4 µA/MHz executing from MRAM (with cache)
    • Low power and deep sleep mode selectable levels of RAM/cache retention

    High-Performance Arm Cortex-M4 Processor with FPU

    • Up to 192 MHz clock frequency
    • Memory protection unit (MPU)
    • Secure Boot
    • PSA-L1 certified

    Bluetooth Low Energy 5.4

    • 2 Mbps, extended advertising packets
    • Angle of Arrival (AoA)/Angle of Departure (AoD)
    • Tx: up to +6 dBm output power
    • Rx Sensitivity: -95 dBm

    Ultra-Low Power Memory

    • Up to 2MB of non-volatile MRAM for code/data
    • Up to 1.4MB of low power SRAM for code/data

    Ultra-Low Power Interface for On- and Off-Chip Sensors

    • 12-bit ADC, 11 selectable input channels
    • Up to 2.8 MS/s sampling rate
    • Temperature sensor with ±3°C accuracy

    Ultra-low Power Flexible Serial Peripherals

    • 2x 2/4/8-bit SPI master interface
    • 1x 2/4/8/16-bit SPI master interface
    • 7x I2C/MSPI for peripheral communication
    • 1x SPI Slave for host communications
    • 4x UART modules with flow control
    • 1x SDIO (SD3.0)/1x eMMC (v4.51)

    Display

    • Up to 500 x 500 resolution
    • Frame Buffer Decompression

    Graphics


    graphicSPOT logo

    • 2D/2.5D graphics accelerator
    • Texture and frame buffer compression
    • Dithering and anti-aliasing

    Audio Processing

    • 1x stereo PDM
    • 1x full-duplex I2S ports

    Rich Set of Clock Sources

    • 16-52 MHz and 32.768 kHz Crystal XTAL oscillators
    • 1 kHz Low Frequency RC (LFRC) oscillator
    • 2x High Frequency RC (HFRC) oscillator – 192/384 MHz

    Power Management

    • Operating range: 1.71-2.2 V, –20°C to 60°C
    • SIMO Buck
    • Multiple I/O voltages

    Applications

    • Smart watches/bands
    • Wireless sensors and IoT
    • Activity and fitness monitors
    • Children’s watches
    • Digital health devices
    • Animal trackers
    • Motion and tracking devices
    • Alarms and security system
    • Far-field voice remotes
    • Predictive maintenance
    • Smart home

    Package Options

    • 4.7 mm x 4.7 mm, 131-pin SIP BGA

    Ordering Information

    • AMA4B2KL-KXR
    • AMA4BLEVB

    apollo4 blue Lite Evaluation Board

    Apollo4 Blue Lite SoC in the BGA package (AMA4B2KL-KXR)

    Low power reference design

    Multiple power/clock options

    USB connector for power/download/debug

    Segger J-Link debugger

    Debugger-in port (J13) (SWD or ETM)

    Three user-controlled LEDs

    Two push buttons for application use, plus a reset push button

    Power slide switch with LED power indicator

    Five headers (J7, J9-J12) for pin/power access to a shield board

    High-speed connector (J8 – QSH-030-01-L-D-A) for interfacing to displays and/or high-speed memory

    RF switch/connector (Murata MM8430-2610RA1) for BLE PHY testing

    Test points for power measurements

    Multiple solder-bridge options for power supply flexibility and peripheral access options

    RoHS compliant

    AP4BLEVB Apollo4 Blue Lite EVB Layout 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB StraightAngle 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB RightAngle 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB Layout 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB StraightAngle 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB RightAngle 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB Layout 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB StraightAngle 1600x800 1
    AP4BLEVB Apollo4 Blue Lite EVB RightAngle 1600x800 1

    Where to Buy

    Apollo4 Blue Lite SoC 192 MHz 1.4MB 2
    Apollo4 Blue Lite SoC 192 MHz 1.4MB

    AMA4B2KL-KXR

    Apollo4 Blue Lite
    Apollo4 Blue Lite EVB Topview Transparent bg scaled

    AMA4BLEVB

    Apollo4 Blue Lite Evaluation Board
    Apollo3 Blue Plus SoC 96 MHz 768KB BGA 2
    Apollo3 Blue Plus SoC 96 MHz 768KB BGA

    AMA3B2KK-KBR

    Apollo3 Blue Plus
    Apollo4 Lite 2
    Apollo4 Lite

    AMAP42KL-KBR

    Apollo4 Lite
    Apollo4 Lite SoC Eval board

    AMAP4LEVB

    Apollo4 Lite Evaluation Board

    Design Resources

    Additional Documentation

    • Set favorites
    • Get update notifications
    • Use search filters
    Visit Content Portal

    Frequently Asked Questions (FAQ)

    • The Apollo4 Blue Lite is an ultra-low-power system-on-chip (SoC) designed for connected edge devices. It combines a 32-bit Arm® Cortex®-M4 processor with floating-point unit (FPU), Bluetooth® Low Energy 5.4 connectivity, and up to 192 MHz performance. It can serve as either an application processor or coprocessor.

    • The Apollo4 Blue Lite features a 32-bit Arm® Cortex®-M4 processor with a floating-point unit (FPU) and Memory Protection Unit (MPU), operating at up to 192 MHz. Ambiq’s turboSPOT® technology enables dynamic performance scaling for ultra-low-power endpoint applications.

    • The Apollo4 Blue Lite supports Bluetooth® Low Energy 5.4 with 2 Mbps operation, extended advertising packets, Angle of Arrival (AoA) and Angle of Departure (AoD), up to +6 dBm transmit power, and -95 dBm receiver sensitivity.

    • Ambiq’s turboSPOT® technology enables the Apollo4 Blue Lite to dynamically scale performance up to 192 MHz. The SoC delivers ultra-low-power processing at 4 µA/MHz when executing from MRAM with cache, helping developers balance processing performance and energy efficiency.

    • The Apollo4 Blue Lite is PSA Certified Level 1 and includes Secure Boot to help protect connected endpoint applications.

    • The Apollo4 Blue Lite features a 2D/2.5D graphics accelerator with texture and frame buffer compression, dithering, and anti-aliasing. It supports displays with resolutions up to 500 × 500 pixels and includes frame buffer decompression.

    • The Apollo4 Blue Lite provides up to 2 MB of non-volatile MRAM for code and data and up to 1.4 MB of low-power SRAM for code and data.

    • The Apollo4 Blue Lite is designed for smartwatches and fitness bands, wireless sensors and IoT devices, activity and fitness monitors, children’s watches, digital health devices, animal trackers, motion and tracking devices, alarms and security systems, far-field voice remotes, predictive maintenance, and smart home applications.
