Atomiq
Ambitious Edge AI
The Atomiq SoC enables a new class of always-on edge AI through SPOT, delivering high-performance NPU workloads with unmatched power efficiency for advanced audio, language, vision, and reasoning.

The Atomiq SoC enables a new class of always-on edge AI through SPOT, delivering high-performance NPU workloads with unmatched power efficiency for advanced audio, language, vision, and reasoning.
01
Atomiq leverages the Arm® Ethos™-U85 NPU to deliver over 200 GOPS of on-device AI performance, with support for sparsity and on-the-fly weight decompression to accelerate complex workloads.
02
SPOT-based ultra-wide range dynamic voltage and frequency scaling (DVFS) enables operation at lower voltages and power than previously possible, making advanced, always-on edge AI practical.
03
Ambiq’s Helia™ AI platform, ADKs, and neuralSPOT® SDK deliver a tightly integrated hardware-software stack that enables high performance, lower memory footprint, ultra-low power, and significantly faster AI deployment.
04
The SPOT platform brings breakthrough ultra-low-power efficiency, dramatically reducing energy consumption for next-generation edge workloads.
Atomiq is Ambiq’s next-generation SoC architecture integrating an NPU, designed to enable scalable, ultra-low-power AI at the edge. It’s built on our patented SPOT® platform and represents a major milestone in how we architect future always-on AI systems.
No. This is a platform milestone announcement, not a commercial product launch. Atomiq is not yet available for customer deployment, and we’re not demonstrating Atomiq silicon at CES. This announcement provides early visibility into our architectural direction and long-term roadmap.
CES is where customers, partners, and investors look for directional signals, not just products. Atomiq reflects years of internal development and customer engagement, and announcing it now helps align the ecosystem around where edge AI is heading—and where Ambiq is investing.
Apollo is the foundation of Ambiq’s current edge AI success. Atomiq extends that foundation, introducing a new system architecture optimized for higher-performance, always-on AI workloads as models grow larger and more complex.
A simple way to think about it:
Apollo powers today’s edge AI deployments; Atomiq defines the next phase.
Absolutely. Apollo remains central to our portfolio and revenue today. Atomiq builds on Apollo’s success—it doesn’t replace it.
Atomiq introduces a system-level architecture designed from the ground up for AI workloads, including a dedicated NPU, while retaining Ambiq’s leadership in ultra-low-power operation through SPOT®. It’s about scaling intelligence without scaling power.
Ethos-U85 provides meaningful gains in AI performance and efficiency, and it aligns well with our SPOT® platform. Together, they enable larger models and more complex workloads at power levels that weren’t previously practical at the edge.
Applications that demand always-on intelligence, such as:
Conversational AR glasses
Advanced wearables
Smart cameras
They represent two ends of the edge AI spectrum—ultra-compact consumer devices and mission-critical industrial systems. Together, they show how Ambiq’s platforms scale across vastly different constraints and use cases.
We haven’t announced availability timelines. We plan to share additional technical details and roadmap updates beginning in March 2026 at Embedded World.
It represents the next step in pushing voltage, power efficiency, and memory architecture even further—enabling more advanced AI at lower energy budgets
Our website use cookies. By continuing navigating, we assume your permission to deploy cookies as detailed in our Privacy Policy.
Hi! How can I help you today?
Welcome back! I see we were discussing your question earlier. Has that been resolved, or would you like to continue where we left off?
Discover the ideal solution for your application.
Discover the ideal solution for your application.
SoC Frequency
SoC
SoC CoreMark®Power Efficiency
NVM
SRAM
Voltage
ADC
UART
I/O
MSPI Master
I²S
Audio
Display
Graphics
Security
Connectivity
RF Sensitivity
Tx Output Power
Packages
Ordering Information
Atomiq
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-

Apollo330M Plus
96 MHz
250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology, Network coprocessor, DMA
Contact Ambiq
2MB
2MB
1.71-3.63V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x) 1x full-duplex I²C/SPI Slave USB 2.0 FS/HS SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR) 1/2/4/8/16-bit wide (1x) up to 250 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x) PLL for Precision Audio
-
-
secureSPOT® 3.0 Arm TrustZone® Security
Bluetooth Low Energy 5.4, Bluetooth Classic, 802.15.4, Thread, and Matter
-95/-98/-104dBm (2Mbps/1Mbps/125kbps)
Up to +14dBm
5.3 x 5.3 mm, BGA with 120 GPIO 4.0 x 4.0 mm, CSP with 68 GPIO
• AP330MPA-CCR (CSP) • AP330MPA-IBR (BGA)

Apollo330B Plus
96 MHz 250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology, Network coprocessor, DMA
Contact Ambiq
2MB
2MB
1.71-3.63V
12-bit, 11 channels, up to 1.7 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x) 1x full-duplex I²C/SPI Slave USB 2.0 FS/HS SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR) 1/2/4/8/16-bit wide (1x) up to 250 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x) PLL for Precision Audio
-
-
secureSPOT® 3.0 Arm TrustZone® Security
Bluetooth Low Energy 5.4
-95/-98/-104dBm (2Mbps/1Mbps/125kbps)
Up to +14dBm
5.3 x 5.3 mm, BGA with 120 GPIO 4.0 x 4.0 mm, CSP with 68 GPIO
• AP330BPA-CCR (CSP) • AP330BPA-ICR (CSP)

Apollo330 Plus
96 MHz
250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology, DMA
Contact Ambiq
2MB
2MB
1.71-3.63V
12-bit, 11 channels, up to 1.7 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x) 1x full-duplex I²C/SPI Slave USB 2.0 FS/HS SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR) 1/2/4/8/16-bit wide (1x) up to 250 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x) PLL for Precision Audio
-
-
secureSPOT® 3.0 Arm TrustZone® Security
-
-
-
5.3 x 5.3 mm, BGA with 120 GPIO 4.0 x 4.0 mm, CSP with 68 GPIO
• AP330NPA-CCR (CSP)
• AP330NPA-IBR (BGA)

Apollo510 Lite
96 MHz
192 / 250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology, DMA
>120
2MB
2MB
1.71-2.2V
12-bit, 11 channels, up to 1.7 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x)
1x full-duplex I²C/SPI Slave
USB 2.0 FS/HS
SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x)
PLL for Precision Audio
SPI 3-wire/4-wire Dual/QuadSPI
MIPI DSI at 1.5 Gbps (2 lanes)
1-layer Display Controller
Memory in Pixel (MiP) Interface
2D/2.5D GPU with anti-aliasing, dithering, and HW vector graphics acceleration
secureSPOT® 3.0
Arm TrustZone® Security
-
-
-
5.3 x 5.3 x 0.8 mm, BGA w/ 120 GPIO
4.0 x 4.0 x 0.5 mm, CSP w/ 68 GPIO
AP510NLA-CCR (CSP), AP510NLA-CBR (BGA)

Apollo510B Lite
96 MHz
192 / 250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology
Network coprocessor, DMA
>120
2MB
2MB
1.71-2.2V
12-bit, 11 channels, up to 1.7 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x)
1x full-duplex I²C/SPI Slave
USB 2.0 FS/HS
SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x)
PLL for Precision Audio
SPI 3-wire/4-wire Dual/QuadSPI
MIPI DSI at 1.5 Gbps (2 lanes)
1-layer Display Controller
Memory in Pixel (MiP) Interface
2D/2.5D GPU with anti-aliasing, dithering, and HW vector graphics acceleration
secureSPOT® 3.0
Arm TrustZone® Security
Bluetooth Low Energy 5.4
-95/-98/-104dBm
(2Mbps/1Mbps/125kbps)
Up to +14dBm
5.3 x 5.3 x 0.8 mm, BGA w/ 120 GPIO
4.0 x 4.0 x 0.5 mm, CSP w/ 68 GPIO
AP510BLA-CCR (CSP), AP510BLA-ICR (CSP)

Apollo510D Lite
96 MHz
192 / 250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology
Network coprocessor, DMA
>120
2MB
2MB
1.71-2.2V
12-bit, 11 channels, up to 1.7 MS/s Sampling Rate ADC
2
I2C/SPI masters (6x)
1x full-duplex I²C/SPI Slave
USB 2.0 FS/HS
SDIO (v3.0) / eMMC (2x)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
1/2/4-bit wide (2x) up to 96 MT/s (SDR/DDR)
I²S Master/Slave full-duplex (1x)
PDM stereo DMIC interface (1x)
PLL for Precision Audio
SPI 3-wire/4-wire Dual/QuadSPI
MIPI DSI at 1.5 Gbps (2 lanes)
1-layer Display Controller
Memory in Pixel (MiP) Interface
2D/2.5D GPU with anti-aliasing, dithering, and HW vector graphics acceleration
secureSPOT® 3.0
Arm TrustZone® Security
Bluetooth Low Energy 5.4
Bluetooth Classic
-95/-98/-104dBm
(2Mbps/1Mbps/125kbps)
Up to +14dBm
5.3 x 5.3 x 0.8 mm, BGA w/ 120 GPIO
4.0 x 4.0 x 0.5 mm, CSP w/ 68 GPIO
AP510DLA-CCR (CSP), AP510DLA-CBR (BGA), AP510DLA-IBR (BGA)

Apollo510B
96 MHz
250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium™ technology, DMA Network coprocessor
120
4MB
3.75MB
1.71-2.2V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (7x)
1x full-duplex/1x half-duplex I²C/SPI Slave
USB 2.0 FS/HS
SDIO v3.0/eMMC (2x)
1/2/4/8-bit wide (1x)
up to 96 MT/s (SDR/DDR)
1/2/4/8/16-bit wide (1x)
up to 250 MT/s (SDR/DDR)
I²S Master/Slave (2x)
full-duplex with ASRC (1x)
PDM stereo DMIC interface (1x)
Low Power Audio ADC (1x)
PLL for Precision Audio
SPI 3-wire/4-wire Dual/QuadSPI
MIPI DSI at 1.5 Gbps (2 lanes)
4-layer Display Controller Memory in Pixel (MiP) Interface
2D/2.5D GPU with anti-aliasing, dithering, and HW vector graphics acceleration
secureSPOT 3.0
Arm TrustZone Security
Bluetooth Low Energy 5.4
-94/-97/-103dBm (2Mbps/1Mbps/125kbps)
Up to +6dBm
5.6 x 5.6 x 0.8 mm,
BGA w/97 GPIO
• AP510BFA-CBR (BGA)
• AP510BEVB (EVB)

Apollo510
96 MHz
250 MHz turboSPOT
32-bit Arm Cortex-M55 with Helium, DMA
Contact Ambiq
4MB
3.75MB
1.71-2.2 V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (8x) 1x full-duplex/1x half-duplex I²C/SPI Slave USB 2.0 FS/HS SDIO v3.0/eMMC (2x) Support for multiple I/O voltages ranging 1.14 to 3.63V
1/2/4/8-bit wide (2x) up to 96 MT/s (SDR/DDR) 1/2/4/8/16-bit wide (2x) up to 250 MT/s (SDR/DDR)
I²S Master/Slave (2x) full-duplex with ASRC (1x)
PDM stereo DMIC interface (1x) Low Power Audio ADC (1x) PLL for Precision Audio
SPI 3-wire/4-wire Dual/QuadSPI MIPI DSI at 1.5 Gbps (2 lanes) 4-layer Display Controller Memory in Pixel (MiP) Interface
2D/2.5D GPU with anti-aliasing, dithering, and vector graphics acceleration
secureSPOT 3.0 Arm TrustZone®
-
-
-
• 6.6 x 6.6 mm, BGA w/ 183 GPIO
• 4.9 x 4.7 mm, CSP w/ 144 GPIO
• AP510NFA-CBR (BGA)
• AP510NFA-CCR (CSP)

Apollo4 Blue Plus
96 MHz, 192 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for Bluetooth Low Energy
29 µW/MHz
2MB
2.75MB
1.71-2.2 V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (7x) I²C/SPI Slave USB 2.0 FS SDIO v3.0/eMMC (1x)
1/2/4/8-bit wide (2x) 1/2/4/8/16-bit wide (KXR pkg only) up to 96 MT/s (SDR/DDR)
I²S Master/Slave (2x) , full-duplex with ASRC
PDM stereo DMIC interface (4x) Low Power Stereo Audio ADC (1x)
SPI 3-wire/4-wire Dual/QuadSPI MIPI DSI at 500 Mbps (1 lane) 4-layer Display Controller
2D/2.5D GPU with anti-aliasing, dithering, and vector graphics assist
secureSPOT 2.0 Secure Boot, Root of Trust
Bluetooth Low Energy 5.4
-95 dBm
Up to +6 dBm
4.7 x 4.7 mm, BGA-131 w/ 81 GPIO
• AMA4B2KP-KXR (BGA)
• AMA4B2KP-KBR (BGA)
• AMAP4BPXEVB (EVB)

Apollo4 Blue Lite
96 MHz, 192 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for Bluetooth Low Energy
38 µW/MHz
2MB
1.4MB
1.71-2.2 V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (7x) I²C/SPI Slave SDIO v3.0/eMMC (1x)
1/2/4/8-bit wide (2x) 1/2/4/8/16-bit wide up to 96 MT/s (SDR/DDR)
I²S Master/Slave, full-duplex
PDM stereo DMIC interface (1x)
SPI 3-wire/4-wire Dual/QuadSPI
2D/2.5D GPU with anti-aliasing and dithering
secureSPOT 2.0 Secure Boot, Root of Trust
Bluetooth Low Energy 5.4
-95 dBm
Up to +6 dBm
• 4.7 x 4.7 mm, BGA-131 w/ 75 GPIO
• AMA4B2KL-KXR (BGA)
• AMA4BLEVB (EVB)

Apollo4 Lite
96 MHz, 192 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA
38 µW/MHz
2MB
1.4MB
1.71-2.2 V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (8x) I²C/SPI Slave SDIO v3.0/eMMC (1x)
1/2/4/8-bit wide (2x) 1/2/4/8/16-bit wide up to 96 MT/s (SDR/DDR)
I²S Master/Slave (2x) full-duplex
PDM stereo DMIC interface (1x)
SPI 3-wire/4-wire Dual/QuadSPI
2D/2.5D GPU with anti-aliasing, and dithering
secureSPOT 2.0 Secure Boot, Root of Trust
Bluetooth Low Energy 5.4
-95 dBm
Up to +6 dBm
• 5 x 5 mm, BGA-146 w/ 84 GPIO
• AMAP42KL-KBR (BGA)
• AMAP4LEVB (EVB)

Apollo4 Plus
96 MHz 192 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA
29 µW/MHz
2MB
2.75MB
1.71-2.2 V
12-bit, 11-channel, up to 2.8 MS/s Sampling Rate ADC
4
I²C/SPI Master (8x) I²C/SPI Slave USB 2.0 FS SDIO v3.0/eMMC (1x)
1/2/4/8-bit wide (2x) 1/2/4/8/16-bit wide up to 96 MT/s (SDR/DDR)
I²S Master/Slave (2x) full-duplex with ASRC
PDM stereo DMIC interface (4x) Low Power Stereo Audio ADC (1x)
SPI 3-wire/4-wire Dual/QuadSPI MIPI DSI at 500 Mbps (2 lanes) 4-layer Display Controller
2D/2.5D GPU with anti-aliasing, dithering, and vector graphics assist
secureSPOT 2.0 Secure Boot, Root of Trust
-
-
-
• 5 x 5 mm, BGA-146 w/ 105 GPIO
• AMAP42KP-KBR (BGA)
• AMAP4PEVB (EVB)
• AMAP4PDISP (Display Kit)

Apollo3 Blue Plus
48 MHz, 96 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for Bluetooth Low Energy
33 µW/MHz
2MB
768KB
1.755-3.63 V
14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC
2
I²C/SPI Master (6x)
1/2/4/8-bit wide (3x) up to 48 MT/s (SDR) ISO7816 Master
I²S Slave for PDM, Audio Pass-through
PDM stereo DMIC interface (1x)
SPI 3-wire/4-wire, Dual/QuadSPI
-
secureSPOT w/ Secure Boot
Bluetooth Low Energy 5
-93 dBm
Up to +3 dBm
• 5.3 x 4.3 x 0.8 mm, BGA-108 w/ 74 GPIO
• AMA3B2KK-KBR (BGA)
• AMA3B2EVB (EVB)

Apollo3 Blue
48 MHz, 96 MHz turboSPOT
32-bit Arm Cortex-M4F, DMA, Arm Cortex-M0 for Bluetooth Low Energy
33 µW/MHz
1MB
384KB
1.755-3.63 V
14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC
2
I²C/SPI Master (6x) I²C/SPI Slave
1/2/4/8-bit wide up to 48 MT/s (SDR) ISO7816 Master
I²S Slave for PDM, Audio Pass-through
PDM stereo DMIC interface (1x)
SPI 3-wire/4-wire
-
secureSPOT
Bluetooth® Low Energy 5
-93 dBm (typical)
Up to +3 dBm
• 5 x 5 mm, BGA-81 w/ 50 GPIO
• 3.25 x 3.37 x 0.51 mm, CSP-66 w/ 37 GPIO
• 3.25 x 3.37 x 0.34 mm, CSP-66 w/ 37 GPIO (Thin)
• 8 x 8 mm, QFN-64 w/ 38 GPIO
• AMA3B1KK-KBR-B0 (BGA)
• AMA3B1KK-KCR-B0 (CSP)
• AMA3B1KK-KCR-TB (Thin CSP)
• AMA3B1KK-KQR-B0 (QFN)
• AMA3BEVB (EVB)

Apollo3
48 MHz 96 MHz turboSPOT®
32-bit Arm Cortex-M4F, DMA
33 µW/MHz
1MB
384KB
1.755-3.63 V
14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC
2
I²C/SPI Master (6x) I²C/SPI Slave
1/2/4/8-bit wide up to 48 MT/s (SDR) ISO7816 Master
I²S Slave for PDM Audio Pass-through
PDM stereo DMIC interface (1x)
SPI 3-wire/4-wire
-
secureSPOT®
-
-
-
• 5 x 5 mm, BGA-81 w/ 50 GPIO
• 3.25 x 3.37 mm, CSP-66 w/ 37 GPIO
• AMAP31KK-KBR (BGA)
• AMAP31KK-KCR (CSP)
• AMA3BEVB

Apollo2
48 MHz
32-bit Arm Cortex-M4F
39 μW/MHz
1MB
256KB
1.755-3.63 V
14-bit, 15-channel, up to 2.67 MS/s Sampling Rate ADC
2
I²C/SPI Master (6x)
-
I²S Slave for PDM Audio Pass-through
PDM stereo DMIC interface (1x)
-
-
-
-
-
-
• 4.5 x 4.5 mm, BGA-64 w/ 50 GPIO
• 2.6 x 2.6 x 0.51 mm, CSP-49 w/ 34 GPIO
• 2.6 x 2.6 x 0.33 mm, CSP-49 w/ 34 GPIO (Thin)
• AMAPH1KK-KBR (BGA)
• AMAPH1KK-KCR (CSP)
• AMAPH1KK-KCR-TB (Thin CSP)
• AMAPHEVB (EVB)

Apollo
24 MHz
32-bit Arm® Cortex®-M4F
92 μW/MHz
512KB
64KB
2.2-3.8 V
10-bit, 13-channel, up to 800 kSps Sampling Rate ADC
1
I²C/SPI Master (2x) I2C/SPI Slave
-
-
-
-
-
-
-
-
-
• 4.5 mm x 4.5 mm, 64-pin BGA with 50 GPIO
• 2.49 mm x 2.90 mm, 41-pin WLCSP with 27 GPIO
• APOLLO512-KBR (BGA)
• APOLLO512-KCR (WLCSP)
• AMAP1EVB (EVB)
First
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Second
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Third
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
No results found for “”
